IC Layout Design Consulting
One discipline, mastered. Layout that meets spec — and ships on time.
We focus exclusively on IC layout design. Engage us as an extension of your team, or hand off complete blocks for execution and sign-off.
Team extension
We plug into your flow, tools and methodology — adding senior layout capacity exactly when and where you need it, without permanent headcount.
Block hand-off
Give us a defined block or subsystem and we deliver it complete — laid out, verified and tape-out-ready against your specs and PDK.
End-to-end layout capabilities
Full-Custom IC Layout
Hand-crafted analog, mixed-signal and RF layout optimised for performance, area and yield.
- Matching-critical device placement
- Parasitic-aware routing
- Area & performance optimisation
Analog & Mixed-Signal Blocks
Layout of bandgaps, ADCs, DACs, PLLs, LDOs, SerDes and other critical analog IP.
- Bandgaps & LDO regulators
- ADC / DAC data converters
- PLLs & SerDes interfaces
Floorplanning & Top-Level Integration
Hierarchical floorplanning, power grid planning and top-level assembly for complex SoCs.
- Hierarchical floorplanning
- Power grid & IR planning
- Top-level SoC assembly
DRC, LVS & Sign-Off
Physical verification, parasitic extraction and tape-out sign-off across leading PDKs.
- DRC / LVS clean closure
- Parasitic extraction (PEX)
- Tape-out sign-off
ESD, Latch-Up & Reliability
ESD protection strategy, latch-up prevention and electromigration / IR-drop aware layout.
- ESD protection strategy
- Latch-up prevention
- EM / IR-drop aware layout
Layout Consultancy & Mentoring
On-site or remote senior support to accelerate your team and de-risk critical projects.
- On-site or remote support
- Team mentoring & reviews
- Project de-risking
Across nodes, processes and foundries
Proven experience from mature nodes down to advanced deep-submicron and mmWave designs.
Nodes
Processes
Foundry support
Have a block that needs laying out?
Tell us about your project and we'll show you exactly how we can plug in.
Discuss your project
